产品描述
 Module size: 320mm*160mm            pixel configuration: 1R,1G,1B

 Pixel pitch: 10mm                                     pixel density: 10000dot/m2

 Resolution: 32dot*16dot                          Scan of Drive: 1/4

Cabinet size: 960mm*640mm                     module Qty: 12pcs

Cabinet Resolution: 96*64                            cabinet pixel: 6144

Weight: 60KG/PCS                                           Area: 0.6144m2

Avarage Power Consumption: 300w/m2     Max Consumption: 750w/m2


Ingress Protection(front/back)                IP65/IP54

Operating Humility                                  10% ~ 90% RH

Operating Temprature                          -20℃ ~ +60℃

Optimal Viewing Distance                   8m-60m

Display Color                                         1,070,000,000

Gray Scale                                            16384grade

Brightness Control                              256grade

Frame Frequency                               60HZ

Refresh Speed                                  >2000HZ

Power Supply                                   110V 220V/50HZ
